Chip, Nano and Pico LED Lights

Size
Color
Voltage
Wire Length
Regular price $2.25
/
  • 4637 items in stock, ready to ship
  • Inventory on the way

Description

These super small LEDs are known as surface mount LEDs, SMD LEDs, or Chip LEDs.

They are very small and compact yet still very, very bright! The benefit of a flat and compact LED Chip,
already wired for you, is that it still gives a great amount of light, but can be mounted flush, with no bulb shape showing.

We have taken these SMD Chip LEDs and taking care with tolerances, added 8 inches of red and green superfine magnet wire.

Get these chips already wired, tested, guaranteed, and fully ready to connect to your power supply. No resistors need to be added, we have done that part!

Need a really, really small LED? Try our new Z-LED
At 0.65mm wide by 0.36mm height by 0.4mm height these LEDs are our smallest.  When it is not lit it is hard to see, so if your project needs a LED that will not be visible until turned-on this is a great choice.

Frequently Asked Questions

"What do I need to run these?"


"How many can I run at once?"

  • Using a 3 volt coin cell holder you can run 1-10 chips.
  • Using a 3 volt AAA holder you can run 1-30 chips
  • Using a 9 volt battery snap/switch you can run 1-50 of the chips.
  • Using a 12 volt 1 Amp supply is also 50 chips, no need to turn off.
  • Using your own power? The chips draw 20 milliamps each. So check your power supply to see how many milliamps it lists. A 1000 milliamp supply can run 50 chips.

"Can the chip LEDs be run along with other LEDs from the same battery or coin cell?"

Yes the chips can be run right alongside all of the other sizes of LEDs on the same power supply.

"On the AC chips, what size is the rectifier/resistor unit?"

evan designs universal rectifier
This diagram shows the size of the rectifier unit

"I need the AC type chips but I have to run them through a tight passage?"

We have a solution! See our separated LEDs here: Separated



This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Customer Reviews

Based on 310 reviews
96%
(298)
3%
(8)
1%
(2)
0%
(1)
0%
(1)
E
Ernesto

Exactly as described 👌

R
R.S.
Prefect Catenary Semaphore Signal Lights

The long wire leads, and the small size of these LEDs allows the installation in semaphore signals suspended by the catenary bridges used on the New Haven RR. While I only purchased one to try out, I'm really happy with this and will have to count the number of semaphores I will need to light and order more. Great modeling item. Thanks.

R
R.S.
Prefect Catenary Semaphore Signal Lights

The long wire leads, and the small size of these LEDs allows the installation in semaphore signals suspended by the catenary bridges used on the New Haven RR. While I only purchased one to try out, I'm really happy with this and will have to count the number of semaphores I will need to light and order more. Great modeling item. Thanks.

T
Ted Fahrenthold
Evans Designs rotating and flashing LED circuits and fire truck siren

Built this 1/25 scale fire truck model using 38 LED lamps in various combinations of flasher and rotating circuits and brough it to life with a fire truck siren module from Evan Designs. Great fun, great products and easy to use. I have opportunity to call for some advice a couple times and these people are responsive, friendly, knowledgeable, and helpful. Customer service like this is dead at most places!! Thanks Evan Designs I will be continue to be a repeat customer!

G
G.O.
Chip size LED

Writing this review reminds me that I forgot to order more that I did for upcoming HO scale projects. They’re great for lighting interiors of buildings. Just these buildings come with such thin walls, sometimes you may have to calculate in a resistor cause Evandesigns LED’s are the best out there. I think you can tone down the brightness with some clear paint.

C
Chris

Fast Shipping!!!

L
L.R.B.
Nano's For Ditch Lights

The warm white nano LEDs work great in small places, such as ditch lights in an O gauge locomotive. I used them in an Atlas locomotive ditch lights since the space was too small for a 3mm LED. They are plenty bright enough.

T
Tom Schupbach
Had what I needed

They had the micro sized LED I wad needing

G
G.F.
“z” LED Indoor Lighting

I find using the warm white “Z” LEDs work great installed in Tichy Lamp Reflectors (#8027) to simulate incandescent lighting in railroad structures (1920’s on).
The yellow “Z” LEDs simulate high pressure sodium lighting for later period industrial and street lighting (1970’s on).

A
Austin Carlton
Great for gunpla

These lights are fantastic for gunpla. The Z is super bright, tiny as all get out and the wiring is so thin you almost don't have to make any wire paths
